To achieve the desired capacitance for your application, you can connect it to different combinations like a series and a parallel combination of a capacitor. Just like the resistor combination, the resultant capacitance is bigger or smaller depending upon the connection. Use the online capacitor in the series calculator for easy calculation.
Capacitors in Series:
Capacitors are called to be connected in series if there is only one path for the flow of current. OR, If the head of the second capacitor is connected to the tail of the first, it is called a series combination as shown in the following circuit.
Apply the KVL to the following circuit will give us
$E=v_{1}+v_{2}+v_{3} \quad \dots(1)$
Where we know that
$v=\frac{Q}{C}$
By putting it to equation (1), we get
$
\frac{Q_{T}}{C_{T}}=\frac{Q_{1}}{C_{1}}+\frac{Q_{2}}{C_{2}}+\frac{Q_{3}}{C_{3}}
\quad \dots(2)$
- What is Aluminum Wiring in Home and Its Dangers?
- 7 Safety Precautions to Take When Doing Electrical Repair at Home
There is only one path for current to flow, so the current for the series circuit same i.e.
$i_{T}=i_{1}=i_{2}=\ldots =i_{n}$
Multiply the above equation by time t will give us
$i_{T}t=i_{1}t=i_{2}t=\ldots =i_{n}t$
Where we know from the basic current definition, that
$it=Q$
So
$Q_{T}=Q_{1}=Q_{2}=\ldots =Q_{n} \quad \dots (3)$
Now put it to the equation (2), so we get
$\frac{Q}{C_{T}}=\frac{Q}{C_{1}}+\frac{Q}{C_{2}}+\frac{Q}{C_{3}}$
Dividing the equation by Q
$\frac{1}{C_{T}}=\frac{1}{C_{1}}+\frac{1}{C_{2}}+\frac{1}{C_{3}} \quad \dots (4)$
- Enhancing Solar Power Systems with Microprocessors: Efficiency, Control, and Optimization
- Unlocking the Power of Semiconductor Memory Chips: A Comprehensive Guide
Capacitors in Series Summary :
- Provide only one path for charging and discharging current.
- The head of the second capacitor is connected to the tail of the first capacitor.
- The charge of all the capacitors connected in the series is the same.
- Adding more capacitors in series will reduce the resultant capacitance.
- The voltage across each capacitor is different.
The Capacitor in the Series Calculator :
Calculate the capacitance with the capacitor in the series calculator. First, put the type of connection and then values of capacitors it will show you the total capacitance either in series connection or in parallel connection.
